Unmatched in elastomeric bridge bearings, we’ve played a key role in over a thousand global projects. Trust SHUANGLIN for reliability, precision, and proven excellence!

Elastomeric bridge bearing pads

Essential in modern bridges, elastomeric bridge bearings, or elastomeric bearings, offer flexibility and stability. Including bearing pads, bridge bearings, laminated elastomeric bearings, and seismic isolators—collectively known as “bridge bearing pads.” Redefine structural support with adaptability and longevity. Elevate your projects with these engineering marvels.

Why Choose Shuanglin Elastomeric Bearing Pad

01. Versatile and Cost-Efficient Solution

- Ideal for vertical loads (<12,000 kN) and movements up to ± 250 mm
- Handles horizontal forces up to 800 kN
- Remarkable rotation capacity of up to 30 mrad
-Operates from -25°C to +50°C

02. Dynamic Performance Powerhouse

- Reduces dynamic load acceleration
- Perfect as dynamic isolators in diverse structures

03. Longevity & Hassle-Free Maintenance

- Corrosion-protected reinforcing plates
- Rigorous rubber compound specifications

04. Industry-Compliant & Service-Rich

- Complies with national and international standards
- CE marked; End-to-end services available

Elastomeric bearing types

Accept various customized solutions

Materials: Quality natural rubber, neoprene, or customized options.
Thickness: 1/8” to 30” or custom.
Width: 36” to 48” or custom widths.
Shapes: Rectangular, square, or round (with optional anchor bolt holes).
Hardness: 50 to 70 durometer (AASHTO compliant).
Loading Capacity: Engineered to handle loads up to [Specify Your Value].
Rotation Angle: Designed to accommodate rotational angles of [Specify Your Value] degrees.
Friction Coefficient: Engineered with a friction coefficient of [Specify Your Value].
Standards: AASHTO, ASTM D4014, BS EN 1337, or as per your requirements.

Feature

Durable Construction: Engineered for long-lasting performance.
Precision Adjustment: Ensure a seamless fit with precise deck displacement.
Seismic Resilience: Enhance safety in seismic-prone areas.
Competitive Pricing: Quality meets affordability for your budget.

Applications:

Bridge Support
Adjustment of Bridge Deck Displacement
Building Seismic Isolation

Structure of Rubber Bearing Pads

Production of Our Bearings According to International and Chinese Standards: ASTM D4014/D4014M. EN 1337-3:2005. ISO 22762-1:2015. GB∕T 20688.4

Outer Rubber Layer (Skin):
- Material: High-quality rubber.
- Function: Enhances durability and environmental resistance.
- Standards: Compliant with ASTM D4014.
Inner Elastomeric Layer (Core):
- Material: Neoprene or natural rubber.
- Function: Absorbs loads, enabling flexibility.
- Standards: Adheres to ASTM D4014 and EN 1337-3.
Reinforcing Steel Plate:
- Material: High-strength steel.
- Function: Boosts load-bearing capacity.
- Standards: Conforms to ASTM A36 or equivalent, and EN 1337-3.

Unrivaled Quality Bridge Elastomeric Pads

Indulge in excellence with our precision-crafted elastomeric pads, born from top-tier rubber.
Enjoy durability, aesthetics, and flawless performance. Our rigorous quality controls and secure packaging guarantee a reliable solution tailored for you.

Installation

Preparation: Ensure a clean and level surface on the bearing supports. Verify that the elastomeric pads match specifications and dimensions.
Placement: Carefully position the elastomeric pads on the designated support points, aligning them accurately with the bridge structure.
Alignment Check: Verify the alignment of the pads to ensure they match the intended layout and can accommodate expected movements.
Fixing in Place: Securely fasten the elastomeric pads in their designated locations, ensuring proper anchoring to prevent displacement.
Final Inspection: Conduct a thorough inspection to confirm that the installed elastomeric bearing pads meet safety and performance standards.
Documentation: Maintain detailed documentation of the installation process, including any adjustments made, for future reference

Note: Always follow the manufacturer’s guidelines and recommended torque specifications during the installation process to ensure optimal performance and longevity of the elastomeric bearing pads.

FAQ

What is the expected lifespan of your elastomeric bearings under normal operating conditions?

Under normal conditions and with proper maintenance, our elastomeric bearings have a service life that can exceed 50 years.

How do your elastomeric bearings perform under heavy dynamic loads?

Our bearings are engineered with a focus on fatigue life under dynamic loads. The rubber compound and steel reinforcement layers are optimized to provide durability and resilience under heavy loads.

How do you test and validate the performance of your bearings?

We conduct a range of tests, including compression, shear, and fatigue tests, to validate the performance of our bearings. We also perform finite element analysis (FEA) and other simulations to ensure that our bearings meet the required specifications.
